Apache Kafka
docker-compose.yaml file for kafka:
version: '3.3'
services:
zookeeper:
container_name: zookeeper-cntr
image: confluentinc/cp-zookeeper:7.2.0
environment:
ZOOKEEPER_CLIENT_PORT: 2181
ZOOKEEPER_TICK_TIME: 2000
restart: always
networks:
- kafka-nw
healthcheck:
test: echo stat | nc zookeeper-cntr 2181
interval: 10s
timeout: 10s
retries: 3
kafka:
container_name: kafka-cntr
image: confluentinc/cp-kafka:7.2.0
depends_on:
- zookeeper
ports:
- 29092:29092
restart: always
environment:
KAFKA_BROKER_ID: 1
KAFKA_ZOOKEEPER_CONNECT: zookeeper-cntr:2181
KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://kafka-cntr:9092,PLAINTEXT_HOST://localhost:29092
KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: PLAINTEXT:PLAINTEXT,PLAINTEXT_HOST:PLAINTEXT
KAFKA_INTER_BROKER_LISTENER_NAME: PLAINTEXT
KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
KAFKA_ADVERTISED_HOST_NAME: localhost
networks:
- kafka-nw
healthcheck:
test: nc -vz kafka-cntr 9092 || exit -1
# start_period: 15s
interval: 5s
timeout: 10s
retries: 10
init-kafka:
image: confluentinc/cp-kafka:7.2.0
depends_on:
- kafka
entrypoint: [ '/bin/sh', '-c' ]
networks:
- kafka-nw
command: |
"
# blocks until kafka is reachable
kafka-topics --bootstrap-server kafka-cntr:9092 --list
echo -e 'Creating kafka topics'
kafka-topics --bootstrap-server kafka-cntr:9092 --create --if-not-exists --topic codespotify-topic --replication-factor 1 --partitions 1
echo -e 'Successfully created the following topics:'
kafka-topics --bootstrap-server kafka-cntr:9092 --list
"
kafka-manager:
image: hlebalbau/kafka-manager:stable
depends_on:
- kafka
restart: always
ports:
- "9000:9000"
environment:
ZK_HOSTS: "zookeeper-cntr:2181"
networks:
- kafka-nw
networks:
kafka-nw:
driver: bridge
--------------------------------------------------------------------------------------------------------------------------------
#version: '3.3'
#services:
# zookeeper:
# container_name: zookeeper-cntr
# image: confluentinc/cp-zookeeper:7.2.0
# environment:
# ZOOKEEPER_CLIENT_PORT: 2181
# ZOOKEEPER_TICK_TIME: 2000
# restart: always
# networks:
# - kafka-nw
# healthcheck:
# test: echo stat | nc zookeeper-cntr 2181
# interval: 10s
# timeout: 10s
# retries: 3
#
# kafka:
# container_name: kafka-cntr
# image: confluentinc/cp-kafka:7.2.0
# depends_on:
# - zookeeper
# ports:
# - 29092:29092
# restart: always
# environment:
# KAFKA_BROKER_ID: 1
# KAFKA_ZOOKEEPER_CONNECT: zookeeper-cntr:2181
# KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://kafka-cntr:9092,PLAINTEXT_HOST://localhost:29092
# KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: PLAINTEXT:PLAINTEXT,PLAINTEXT_HOST:PLAINTEXT
# KAFKA_INTER_BROKER_LISTENER_NAME: PLAINTEXT
# KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
# KAFKA_ADVERTISED_HOST_NAME: localhost
# networks:
# - kafka-nw
# healthcheck:
# test: nc -vz kafka-cntr 9092 || exit -1
# # start_period: 15s
# interval: 5s
# timeout: 10s
# retries: 10
#
# init-kafka:
# image: confluentinc/cp-kafka:7.2.0
# depends_on:
# - kafka
# entrypoint: [ '/bin/sh', '-c' ]
# networks:
# - kafka-nw
# command: |
# "
# # blocks until kafka is reachable
# kafka-topics --bootstrap-server kafka-cntr:9092 --list
#
# echo -e 'Creating kafka topics'
# kafka-topics --bootstrap-server kafka-cntr:9092 --create --if-not-exists --topic codespotify-topic --replication-factor 1 --partitions 1
#
# echo -e 'Successfully created the following topics:'
# kafka-topics --bootstrap-server kafka-cntr:9092 --list
# "
#
# kafka-manager:
# image: hlebalbau/kafka-manager:stable
# depends_on:
# - kafka
# restart: always
# ports:
# - "9000:9000"
# environment:
# ZK_HOSTS: "zookeeper-cntr:2181"
# networks:
# - kafka-nw
#
#networks:
# kafka-nw:
# driver: bridge
version: '3.7'
services:
zookeeper:
image: zookeeper
container_name: zookeeper
ports:
- "2181:2181"
kafka:
image: bitnami/kafka
container_name: kafka
depends_on:
- zookeeper
ports:
- "9092:9092"
environment:
KAFKA_ADVERTISER_HOST_NAME: localhost
KAFKA_ZOOKEEPER_CONNECT: zookeeper:2181
kafdrop:
image: obsidiandynamics/kafdrop
container_name: kafdrop
depends_on:
- kafka
environment:
KAFKA_BROKERCONNECT: "kafka:9092"
ports:
- "9000:9000"
cd bitnami
cd kafka
cd bin
kafka-topics.sh --create --bootstrap-server localhost:9092 --replication-factor 1 --partitions 1 --topic quickstart
kafka-console-producer.sh --topic quickstart --bootstrap-server localhost:9092
----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Start zookeeper:
./zookeeper-server-start.sh ../config/zookeeper.properties
Start kafka:
./kafka-server-start.sh ../config/server.properties
1. for creating topic on cmd: (you have to be in bin folder)
./kafka-topics.sh --bootstrap-server localhost:9092 --create --topic my-first-topic --partitions 3 --replication-factor 1
2. for knowing the list of topics:
./kafka-topics.sh --bootstrap-server localhost:9092 --list
./kafka-topics.sh --bootstrap-server localhost:9092 --describe --topic my-third-topic
4. to delete topic:
./kafka-topics.sh --bootstrap-server localhost:9092 --delete --topic my-first-topic
5. read messages:
./kafka-console-consumer.sh --bootstrap-server localhost:9092 --topic my-first-topic --from-beginning ---partition 0
6. send message:
./kafka-console-producer.sh --broker-list localhost:9092 --topic my-first-topic
7. list of groups:
./kafka-consumer-groups.sh --bootstrap-server localhost:9092 --list
8. information about group:
./kafka-consumer-groups.sh --bootstrap-server localhost:9092 --describe --group group1
==============================================================================================================================================================================================================
*** We cannot decrease number of topics, but we can increase it.
-- Kafka Broker is a program. It can be a physical computer or a virtual machine that runs kafka processes. We can start multiple brokers in a cluster.
** There is no Kafka broker always acts as a leader.
1. Create storage directory for Kafka cluster: inside kafka folder:
./bin/kafka-storage.sh random-uuid
This command creates unique identifier to configure kafka cluster.
2. Format log directory:
./bin/kafka-storage.sh format -t K8pcZzGQSeSUdMAhiDbeyg -c config/kraft/server.properties
3. Run Kafka server:
./bin/kafka-server-start.sh config/kraft/server.properties
4. To stop Kafka servers gracefully:
./bin/kafka-server-stop.sh
5. Creating Kafka Topic: first of all we have to enter to the bin folder:
./kafka-topics.sh --create --topic topic2 --partitions 3 --replication-factor 3 --bootstrap-server localhost:9092,localhost:9094,localhost:9096
6. To show list of kafka topics:
./kafka-topics.sh --list --bootstrap-server localhost:9092
7. To show detailed information about topics:
./kafka-topics.sh --describe --bootstrap-server localhost:9092
8. Delete Kafka topic:
./kafka-topics.sh --delete --topic topic1 --bootstrap-server localhost:9092
9. Producing Kafka message without a key:
./kafka-console-producer.sh --bootstrap-server localhost:9092,localhost:9094 --topic my-topic
10. Producing Kafka message with key:
./kafka-console-producer.sh --bootstrap-server localhost:9092,localhost:9094 --topic my-topic --property "parse.key=true" --property "key.separator=:"
11. Consuming messages from Kafka topic from the beginning:
./kafka-console-consumer.sh --topic my-topic --from-beginning --bootstrap-server localhost:9092
veya
./kafka-console-consumer.sh --topic product-created-events-topic --from-beginning --bootstrap-server localhost:9092 --property print.key=true
12. Consuming messages from Kafka topic from the beginning with key and value as well:
./kafka-console-consumer.sh --topic my-topic --from-beginning --bootstrap-server localhost:9092 --property print.key=true --property print.value=true
12. Add or update existing configuration:
./bin/kafka-configs.sh --bootstrap-server localhost:9092 --alter --entity-type topics --entity-name topic2 --add-config min.insync.replicas=2
13. Consuming messages from Dead Letter Topic:
./bin/kafka-console-consumer.sh --bootstrap-server localhost:9092 --topic product-created-events-topic.DLT --from-beginning --property print.key=true --property print.value=true
***14. Operating inside docker container:
1) docker ps
2) docker exec -it <container-id, or name> /bin/bash
3) cd opt/bitnami/kafka
4)kafka-console-consumer.sh --bootstrap-server host.docker.internal:9092 --topic product-created-events-topic.DLT --from-beginning --property print.key=true --property print.value=true
all other command are the same
*** here we must pay attention host.docker.internal, because we are inside container, if we write as above all brokers will see each others, otherwise we can write localhost:9092 this will work only for the container that we are inside
=================================================================================================================================================================================================================================
yaml file for one kafka broker with kraft:
version: '3.8' # Updated version
services:
kafka1:
image: bitnami/kafka:latest # Use Bitnami's Kafka image which supports KRaft mode
hostname: kafka1
container_name: kafka1
ports:
- "9092:9092"
environment:
- KAFKA_CFG_NODE_ID=1
- KAFKA_CFG_PROCESS_ROLES=broker,controller
- KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka1:9093
- KAFKA_CFG_LISTENERS=PLAINTEXT://:9092,CONTROLLER://:9093
- KAFKA_CFG_ADVERTISED_LISTENERS=PLAINTEXT://localhost:9092
- KAFKA_CFG_LISTENER_SECURITY_PROTOCOL_MAP=PLAINTEXT:PLAINTEXT,CONTROLLER:PLAINTEXT
- KAFKA_CFG_INTER_BROKER_LISTENER_NAME=PLAINTEXT
- KAFKA_CFG_AUTO_CREATE_TOPICS_ENABLE=true
- KAFKA_CFG_LOG_DIRS=/opt/bitnami/kafka/data
- KAFKA_CFG_OFFSETS_TOPIC_REPLICATION_FACTOR=1
- KAFKA_CFG_TRANSACTION_STATE_LOG_REPLICATION_FACTOR=1
- KAFKA_CFG_TRANSACTION_STATE_LOG_MIN_ISR=1
- KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
- ALLOW_PLAINTEXT_LISTENER=yes # Allows plaintext communication
volumes:
- ./data/kafka:/opt/bitnami/kafka/data
networks:
- kafka-network
networks:
kafka-network:
driver: bridge
yaml file for multiple kafka broker with kraft with kafka-ui:
version: "3"
services:
kafka1:
image: bitnami/kafka
container_name: kafka1
ports:
- 9092:9092 # Expose external listener port
environment:
- KAFKA_ENABLE_KRAFT=yes
- KAFKA_CFG_PROCESS_ROLES=broker,controller
- KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
- KAFKA_CFG_LISTENERS=INTERNAL://:9093,EXTERNAL://:9092,CONTROLLER://:29093
- KAFKA_CFG_LISTENER_SECURITY_PROTOCOL_MAP=INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT
- KAFKA_CFG_ADVERTISED_LISTENERS=INTERNAL://kafka1:9093,EXTERNAL://localhost:9092
- KAFKA_CFG_INTER_BROKER_LISTENER_NAME=INTERNAL
- KAFKA_BROKER_ID=1
- KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka1:29093,2@kafka2:29093,3@kafka3:29093
- ALLOW_PLAINTEXT_LISTENER=yes
- KAFKA_CFG_NODE_ID=1
- KAFKA_KRAFT_CLUSTER_ID=MkU3OEVBNTcwNTJENDM2Qk # Replace with your cluster ID
volumes:
- ./kafka1:/bitnami/kafka
kafka2:
image: bitnami/kafka
container_name: kafka2
ports:
- 9093:9093 # Expose external listener port
environment:
- KAFKA_ENABLE_KRAFT=yes
- KAFKA_CFG_PROCESS_ROLES=broker,controller
- KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
- KAFKA_CFG_LISTENERS=INTERNAL://:9094,EXTERNAL://:9093,CONTROLLER://:29093
- KAFKA_CFG_LISTENER_SECURITY_PROTOCOL_MAP=INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT
- KAFKA_CFG_ADVERTISED_LISTENERS=INTERNAL://kafka2:9094,EXTERNAL://localhost:9093
- KAFKA_CFG_INTER_BROKER_LISTENER_NAME=INTERNAL
- KAFKA_BROKER_ID=2
- KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka1:29093,2@kafka2:29093,3@kafka3:29093
- ALLOW_PLAINTEXT_LISTENER=yes
- KAFKA_CFG_NODE_ID=2
- KAFKA_KRAFT_CLUSTER_ID=MkU3OEVBNTcwNTJENDM2Qk # Use the same cluster ID as kafka1
volumes:
- ./kafka2:/bitnami/kafka
kafka3:
image: bitnami/kafka
container_name: kafka3
ports:
- 9094:9094 # Expose external listener port
environment:
- KAFKA_ENABLE_KRAFT=yes
- KAFKA_CFG_PROCESS_ROLES=broker,controller
- KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
- KAFKA_CFG_LISTENERS=INTERNAL://:9095,EXTERNAL://:9094,CONTROLLER://:29093
- KAFKA_CFG_LISTENER_SECURITY_PROTOCOL_MAP=INTERNAL:PLAINTEXT,EXTERNAL:PLAINTEXT,CONTROLLER:PLAINTEXT
- KAFKA_CFG_ADVERTISED_LISTENERS=INTERNAL://kafka3:9095,EXTERNAL://localhost:9094
- KAFKA_CFG_INTER_BROKER_LISTENER_NAME=INTERNAL
- KAFKA_BROKER_ID=3
- KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka1:29093,2@kafka2:29093,3@kafka3:29093
- ALLOW_PLAINTEXT_LISTENER=yes
- KAFKA_CFG_NODE_ID=3
- KAFKA_KRAFT_CLUSTER_ID=MkU3OEVBNTcwNTJENDM2Qk # Use the same cluster ID as kafka1
volumes:
- ./kafka3:/bitnami/kafka
kafka-ui:
image: provectuslabs/kafka-ui:latest
container_name: kafka-ui
ports:
- 8080:8080
environment:
KAFKA_CLUSTERS_0_NAME: local
KAFKA_CLUSTERS_0_BOOTSTRAPSERVERS: kafka1:9093,kafka2:9094,kafka3:9095
KAFKA_CLUSTERS_0_ZOOKEEPER: "" # Empty since you're using KRaft, not Zookeeper
KAFKA_CLUSTERS_0_KAFKA_CONNECT_ENABLED: "false"
KAFKA_CLUSTERS_0_SCHEMAREGISTRY_ENABLED: "false"
depends_on:
- kafka1
- kafka2
- kafka3
